Featuring X-Torq® engine for lower fuel consumption and reduced emission levels.
Equipped with fuel pump/ primer bulb and auto return stop switch for easier starting.
|Cylinder displacement||38 cm³|
|Power output||1.6 kW/ 2.2hp|
|Maximum power speed||9000 rpm|
|Maximum recommended engine speed||12000 rpm|
|Cylinder bore||41 mm / 1.61 inch|
|Cylinder stroke||31 mm / 1.22 inch|
|Ignition system||SEM DM60|
|Ignition module air gap||0.3 mm / 0.01 "|
|Spark plug||Champion RCJ7Y, Husqvarna HQT-1, NGK BPMR7A|
|Electrode gap||0.5 mm / 0.02 "|
|Carburettor model name||Zama EL41|
|Fuel tank volume||0.37 lit / 0.78 US pint|
|Oil tank volume||0.25 lit / 0.53 US pint|
|Oil pump type||Adjustable flow, no flow at idle|
|Oil pump capacity||13-13 ml/min|
|Fuel consumption||652 g/kWh|
|Chain pitch||3/8" LP|
|Recommended bar length, min-max||35-40 cm / 14"-16"|
|Chain speed at max power||17.1 m/s / 56.1 fts|
|Emission, vibration & noise data|
|Equivalent vibration level (ahv , eq) front / rear handle||3.72/5.5 m/s²|
|Sound pressure level at operators ear||102 dB(A)|
|Sound power level, guaranteed (LWA)||116 dB(A)|
|Weight (excl. cutting equipment)||4.7 kg|
Deliver lower fuel consumption and reduced exhaust emission levels in accordance with the world´s most stringent environmental regulations.
Centrifugal air cleaning system for reduced wear and longer operating time between filter cleanings.
Ergonomic rear handle
Increased comfort with soft inlay, ergonomic trigger and asymmetrical handle.
Distinct felling marks for better felling precision.
Side-mounted chain tensioner
Side-mounted chain tensioner makes chain adjustment quick and easy.
Snap-lock cylinder cover
Snap-lock cylinder cover saves time when changing spark plugs and cleaning.
Effective anti-vibration dampeners absorb vibration, sparing the user's arms and hands.
The engine and starter have been designed so the machine starts quickly with minimum effort. Resistance in the starter cord is reduced by up to 40%
